When you work with an AI coding agent like Codex, the real productivity gains come from letting it interact with the systems around your code — not just the code itself. Connecting Codex to Google Workspace via the Model Context Protocol (MCP) lets it search Gmail, read messages, download attachments, manage drafts, and access Calendar, Drive, Docs, Sheets, and more — all within a single conversation session.

Without a stable MCP setup, you end up copy-pasting context between tools, breaking your flow. In this post, we will walk through the recommended setup for Google Workspace MCP with Codex, covering installation, OAuth authentication, available tools, and how to troubleshoot common failures.

Version note: This guide was verified on March 20, 2026 using Google Workspace MCP v0.0.7 (released March 11, 2026).

Why a Pinned Local Install

The most common approach people try first is running the MCP server via npx at runtime. This works for quick experiments but causes two problems in practice:

  • Version drift — npx fetches the latest release every time Codex starts, so a server update can silently break your configured tool names or OAuth flow.
  • Cold start latency — downloading and compiling on each session adds startup time that disrupts the agent loop.

The reliable alternative is to clone a pinned release locally, build it once, and point Codex at the compiled dist/index.js entrypoint. This gives you a stable path in ~/.codex/config.toml and a predictable server version until you explicitly choose to upgrade.

Prerequisites

Before starting, make sure you have:

  • Codex CLI with MCP support enabled
  • Node.js and npm installed
  • A Google account with access to the Workspace data you want Codex to use
  • A browser available for the OAuth flow
  • A terminal with access to macOS Keychain, or file-storage fallback if Keychain is unavailable

Setup

Step 1: Remove Any Existing Google Workspace MCP Entry

If you previously experimented with a Gmail or Workspace MCP entry, remove it first to avoid conflicts:

codex mcp remove google_workspace

If the server was never configured, this command will fail — that is expected. Continue to the next step.

Step 2: Clone a Pinned Copy

We pin to v0.0.7 to ensure a stable, tested build. Clone it into ~/.codex/vendor to keep it separate from your project code:

mkdir -p ~/.codex/vendor
git clone --branch v0.0.7 --depth 1 \
  https://github.com/gemini-cli-extensions/workspace.git \
  ~/.codex/vendor/google-workspace

The --depth 1 flag fetches only the tagged commit, keeping the download small.

Step 3: Build the Server

Run both build steps from the cloned directory:

cd ~/.codex/vendor/google-workspace
npm install
npm run build:auth-utils -w workspace-server

npm install compiles the main MCP server. The build:auth-utils step compiles the headless login helper you will use in the next step. Both are required — skipping the second step means the OAuth login command will not be available.

Step 4: Add the MCP Server to Codex Config

Edit ~/.codex/config.toml and add the following block, replacing <your-user> with your actual macOS username:

[mcp_servers.google_workspace]
command = "node"
args = ["/Users/<your-user>/.codex/vendor/google-workspace/workspace-server/dist/index.js", "--debug", "--use-dot-names"]
cwd = "/Users/<your-user>/.codex/vendor/google-workspace"

The --use-dot-names flag is important — it exposes tool names in the gmail.search format rather than underscore variants, which is what most prompts and docs reference.

Step 5: Authenticate via OAuth

Run the headless login helper:

cd ~/.codex/vendor/google-workspace
node scripts/auth-utils.js login

The helper prints a Google OAuth URL. Complete the flow:

  1. Open the URL in your browser.
  2. Sign in to the Google account you want Codex to use.
  3. Approve the requested Workspace scopes.
  4. Copy the credentials JSON shown by the browser.
  5. Paste it into the terminal and press Enter twice.

The credentials are saved to macOS Keychain (or an encrypted file if Keychain is unavailable).

Step 6: Verify Authentication

Confirm both tokens were saved:

cd ~/.codex/vendor/google-workspace
node scripts/auth-utils.js status

A successful result shows both an access token and a refresh token marked as present. If either is missing, re-run the login step.

Step 7: Restart Codex

Start a new Codex session so the new MCP server is loaded. Then confirm it registered correctly:

codex mcp get google_workspace
codex mcp list

You should see google_workspace in the list with its tools enumerated.

Available Gmail Tools

Once connected, Codex can use the following Gmail tools within the MCP session:

Tool Purpose
gmail.search Search messages by query string
gmail.get Read a specific message by ID
gmail.downloadAttachment Download an attachment from a message
gmail.send Send a new email
gmail.createDraft Create a draft without sending
gmail.sendDraft Send a previously created draft
gmail.modify Add or remove labels on a message
gmail.batchModify Modify labels on multiple messages
gmail.modifyThread Modify labels on an entire thread
gmail.listLabels List all labels in the account
gmail.createLabel Create a new label

Beyond Gmail, the same server exposes tools for Drive, Calendar, Docs, Sheets, Slides, Chat, and People — all accessible from a single MCP connection.

Troubleshooting

Status Says “No Credentials Found” After Login

This typically means the status command ran in a different process context than where the credentials were saved — most commonly a sandboxed terminal or IDE terminal that cannot access the same Keychain backend.

Re-run the status check from a standard macOS terminal (Terminal.app or iTerm2), not from within an IDE or restricted shell. If the problem persists, switch to file-based storage (see below).

/dev/tty or Terminal Prompt Errors During Login

The headless login helper reads the pasted credentials JSON from a real terminal device. Sandboxed environments that block /dev/tty (some CI runners, restricted IDE terminals) will fail here.

Run the login command from a normal local terminal session, then verify with status before returning to your IDE.

Keychain Is Unavailable

If macOS Keychain is not accessible, force the server to use encrypted file storage instead:

export GEMINI_CLI_WORKSPACE_FORCE_FILE_STORAGE=true
node scripts/auth-utils.js login

Set the same environment variable when checking status or starting the server later, so both operations use the same storage backend consistently.

Server Does Not Appear in Codex

Check these three things in order:

  1. The [mcp_servers.google_workspace] block exists in ~/.codex/config.toml
  2. The file ~/.codex/vendor/google-workspace/workspace-server/dist/index.js exists
  3. Codex was restarted after the config change

Updating to a Newer Release

When a new version is available and you want to upgrade:

cd ~/.codex/vendor/google-workspace
git fetch --tags
git checkout v0.0.8   # replace with the target version
npm install
npm run build:auth-utils -w workspace-server

Re-run the OAuth login step after upgrading, as new releases may request additional scopes.

Security Considerations

Before using this integration in day-to-day work, keep the following in mind:

  • The MCP server authenticates as your Google account and can read and modify Gmail, Drive, Calendar, and other Workspace data.
  • Only enable it in Codex sessions you trust — avoid shared or multi-user environments.
  • The OAuth consent covers broad Workspace scopes, not only Gmail. Review what scopes are requested during login.
  • Review write operations (send, createDraft, modify) carefully before approving them in the agent loop.
  • Never paste live OAuth credentials into shared logs, tickets, or untrusted chat sessions.

Conclusion

By following this setup, Codex gains persistent, stable access to Google Workspace without runtime dependency resolution or version surprises. The key decisions that make this reliable are:

  • Pinned local clone — eliminates version drift between sessions
  • Pre-built dist artifact — no compile step at agent startup
  • Headless OAuth helper — runs outside the agent process to avoid sandbox restrictions
  • --use-dot-names flag — exposes the standard gmail.search-style tool names

Start with gmail.search and gmail.get to validate the connection, then expand to the Drive and Calendar tools as your workflows demand.
