Building Intelligent Multi-Agent Systems with Coordinators

In the rapidly evolving landscape of AI-powered applications, we’re seeing a shift from monolithic single-agent systems to sophisticated multi-agent architectures. While a single AI agent might seem simpler, complex domains like incident response, customer support, and technical troubleshooting often require specialized expertise that no single agent can effectively provide.

This post explores how to build intelligent coordinator agents that automatically route queries to specialized expert agents, creating a system that’s both more effective and more maintainable than traditional approaches.

The Problem with Single-Agent Systems

Imagine building a technical support system. A single agent needs to handle everything from:

• Complex code debugging and root cause analysis
• Infrastructure outages and performance issues
• Product how-to questions and feature explanations
• Feature requests and business inquiries

Each of these domains requires different methodologies, tools, and expertise. A single agent becomes a “jack of all trades, master of none” - decent at everything but excellent at nothing.

Enter the Multi-Agent Coordinator Pattern

The coordinator pattern solves this by introducing a smart router that:

1. Analyzes incoming queries to understand intent and domain
2. Classifies queries into specific categories
3. Routes queries to specialized expert agents
4. Orchestrates the overall response flow

Let’s dive into how to implement this pattern effectively.

Architecture Overview

@startuml Multi-Agent Coordinator Components

!theme plain

package "Multi-Agent Coordinator System" {

    package "User Interface Layer" {
        [Slack Bot] as slack
        [Web Interface] as web
        [API Gateway] as api
    }

    package "Coordination Layer" {
        [Coordinator Agent] as coordinator
        [Query Classifier] as classifier
        [Configuration Manager] as config
        [Routing Engine] as router
    }

    package "Specialized Agents" {
        [Developer Agent] as dev
        [SRE Agent] as sre
        [Product Agent] as product
    }

    package "Tools & Services Layer" {
        [Investigation Tools] as investigation
        [Code Analysis Tools] as codetools
        [Metrics Tools] as metrics
        [Knowledge Base] as kb
        [Tracing Manager] as tracing
    }

    package "External Integrations" {
        [Confluence API] as confluence
        [Jira API] as jira
        [Datadog API] as datadog
        [GitHub API] as github
    }

    package "Infrastructure" {
        [Azure OpenAI] as openai
        [Cache Layer] as cache
        [Configuration Store] as configstore
        [Logging System] as logs
    }

    ' User Interface connections
    slack --> coordinator
    web --> coordinator
    api --> coordinator

    ' Coordinator connections
    coordinator --> classifier
    coordinator --> config
    coordinator --> router
    classifier --> openai

    ' Router connections
    router --> dev
    router --> sre
    router --> product

    ' Agent tool connections
    dev --> investigation
    dev --> codetools
    dev --> tracing

    sre --> investigation
    sre --> metrics

    product --> kb
    product --> investigation

    ' Tools to external services
    investigation --> confluence
    investigation --> jira
    investigation --> datadog

    codetools --> github
    metrics --> datadog
    kb --> confluence
    kb --> jira

    ' Infrastructure connections
    coordinator --> cache
    coordinator --> logs
    config --> configstore

    ' All agents use OpenAI
    dev --> openai
    sre --> openai
    product --> openai
}

note right of coordinator
  Central orchestrator that:
  - Classifies incoming queries
  - Routes to specialized agents
  - Maintains conversation context
  - Provides unified responses
end note

note right of dev
  Specialized for:
  - Root cause analysis
  - Code-level debugging
  - Technical issue resolution
  - Hypothesis-driven investigation
end note

note right of sre
  Specialized for:
  - Incident response
  - System health monitoring
  - MTTR optimization
  - Infrastructure issues
end note

note right of product
  Specialized for:
  - Product knowledge
  - Feature explanations
  - How-to guidance
  - Documentation retrieval
end note

@enduml

Sequence diagram to handle a complex query:

@startuml Multi-Agent Query Processing Sequence

!theme plain

actor User
participant "Slack Bot" as slack
participant "Coordinator" as coord
participant "Classifier" as classifier
participant "Azure OpenAI" as openai
participant "Developer Agent" as dev
participant "Investigation Tools" as investigation
participant "Tracing Manager" as tracing
participant "External APIs" as external

User -> slack: "@bot The login API returns 500 errors for call_id abc-123"

slack -> coord: process_query(query, context)

coord -> classifier: classify_query(query, history)
classifier -> openai: analyze_query_intent(prompt, examples)
openai -> classifier: classification_result
classifier -> coord: ClassificationResult{\n  category: "technical_bug_report",\n  confidence_score: 9,\n  handoff_agent: "developer_agent"\n}

alt confidence_score >= 5
    coord -> dev: run_analysis(query, context)

    dev -> investigation: investigate_logs(call_id="abc-123")
    investigation -> external: search_logs(filters)
    external -> investigation: log_entries[]
    investigation -> dev: log_analysis_result

    dev -> tracing: trace_execution(call_id="abc-123", hypothesis)
    tracing -> external: get_traces(trace_id)
    external -> tracing: trace_data
    tracing -> dev: execution_analysis

    dev -> openai: synthesize_findings(logs, traces, hypothesis)
    openai -> dev: root_cause_analysis

    dev -> coord: DeveloperResult{\n  analysis: "Root cause identified...",\n  confidence_score: 8,\n  recommendations: [...]\n}

else confidence_score < 5
    coord -> coord: route_to_human_review()
end

coord -> slack: QueryResponse{\n  response: formatted_analysis,\n  metadata: {...}\n}

slack -> User: **Root Cause Analysis**\n\nThe 500 errors are caused by...\n\n**Recommendations:**\n1. Fix null pointer in PaymentService\n2. Add validation for edge cases\n3. Improve error handling

note over coord, dev
  The Developer Agent follows a structured methodology:
  1. Initial Assessment
  2. Evidence Gathering (logs)
  3. Hypothesis Formulation
  4. Code-Level Validation (tracing)
  5. Synthesis & Recommendations
end note

@enduml

Implementation Deep Dive

1. Configuration-Driven Category Definition

The first key insight is making your routing logic configuration-driven rather than hardcoded. Here’s how we define categories:

# flow_config/coordinator.yaml
categories:
    - name: "technical_bug_report"
      instructions: >
          Classify as a technical bug report if the user is reporting that an
          existing feature is broken, producing an error, or not behaving as expected.

          KEYWORDS: bug, error, broken, doesn't work, crash, exception, call_id

          EXAMPLES:
          - "When I click the 'Save' button, I get a 500 error. The call_id is abc-123."
          - "The login page is stuck in a loading loop."
      handoff: "developer_agent"

    - name: "infrastructure_outage_or_performance"
      instructions: >
          Classify if the problem relates to system availability, widespread
          slowness, or core connectivity issues.

          KEYWORDS: down, slow, unavailable, outage, performance, timing out
      handoff: "sre_agent"

This approach provides several benefits:

• Easy updates without code changes
• Clear documentation of routing logic
• Non-technical stakeholders can understand and modify rules
• A/B testing of different routing strategies

2. The Coordinator Agent Implementation

Here’s the core coordinator logic:

class CoordinatorAgent:
    def __init__(self, config_path: str = "flow_config/coordinator.yaml"):
        self.config = self._load_config()
        self.classifier_agent = self._create_classifier_agent()

    def _create_classifier_agent(self) -> Agent:
        """Create the classification agent with dynamic prompt based on config."""

        # Build category descriptions from config
        categories_text = ""
        for i, category in enumerate(self.config.categories, 1):
            categories_text += (
                f"{i}. **{category.name}** (handoff: {category.handoff}):\n"
                f"   {category.instructions.strip()}\n\n"
            )

        prompt = f"""
You are an issue classification agent that categorizes user queries and routes
them to appropriate specialist agents.

Based on the user's query, you must classify it into one of the following categories:

{categories_text}

**Output Requirements:**
- category: The exact category name from the list above
- confidence_score: Integer from 0-10 (10 = highest confidence)
- reasoning: Clear explanation of why this category was chosen
- handoff_agent: The agent that should handle this query
"""

        return Agent(
            name="IssueClassifier",
            instructions=prompt,
            output_type=ClassificationResult,
            model=get_azure_model(),
            tools=[investigation_agent_tool],
        )

3. Structured Classification Output

The coordinator produces structured output for reliable routing:

class ClassificationResult(BaseModel):
    category: str
    """The classified category name."""
    confidence_score: int
    """The confidence score from 0-10, where 10 is highest confidence."""
    reasoning: str
    """The reasoning behind the classification."""
    handoff_agent: str
    """The agent to handoff the request to."""

4. Specialized Expert Agents

Each expert agent is designed with domain-specific methodologies:

Developer Agent - Root Cause Analysis Specialist

DEVELOPER_PROMPT = """
# ROLE & GOAL
You are a world-class **Developer Agent**, an expert in diagnosing and resolving
critical incidents in distributed software systems.

# CORE METHODOLOGY
1. **Initial Assessment**: Understand the incident's context
2. **Evidence Gathering**: Use investigation tools to query logs
3. **Hypothesis Formulation**: Create testable hypotheses about root causes
4. **Code-Level Validation**: Use tracing tools to validate hypotheses
5. **Synthesize & Conclude**: Consolidate findings into actionable recommendations

# TOOLS
- `investigation_agent_tool`: High-level log analysis
- `tracing_agent_tool`: Deep code execution tracing
"""

SRE Agent - Incident Response Specialist

SRE_PROMPT = """
# ROLE & GOAL
You are a world-class **SRE Agent**, focused on Mean Time to Recovery (MTTR),
not deep root cause analysis.

# CORE METHODOLOGY
1. **Triage & Impact Assessment**: Understand blast radius and severity
2. **Evidence Gathering**: Check system health metrics and recent events
3. **Hypothesis Formulation**: Form system-level failure hypotheses
4. **Mitigation Planning**: Propose fastest, safest actions to restore service
5. **Synthesize & Conclude**: Clear impact summary and mitigation steps

# FOCUS
Prioritize rapid recovery over thorough analysis. Rollbacks over code fixes.
"""

The Magic of Specialization

Each agent has fundamentally different approaches:

Aspect	Developer Agent	SRE Agent	Product Agent
Primary Goal	Root cause analysis	Service restoration	Knowledge sharing
Time Horizon	Deep investigation	Immediate response	Thorough explanation
Methodology	Hypothesis-driven debugging	Rapid triage process	Systematic information retrieval
Success Metric	Accuracy of diagnosis	MTTR (Mean Time to Recovery)	User comprehension
Tools	Code tracing, debugging	Metrics, infrastructure monitoring	Documentation, knowledge base

This specialization leads to dramatically better outcomes than a generalist approach.

Advanced Patterns and Best Practices

1. Confidence Scoring and Fallbacks

async def run(self, query_context: QueryContext) -> QueryResponse:
    result = await Runner.run(self.classifier_agent, input_text)
    classification = result.final_output_as(ClassificationResult)

    # Handle low confidence classifications
    if classification.confidence_score < 5:
        logger.warning(f"Low confidence classification: {classification.confidence_score}")
        # Could route to human review or general support

    # Route to specialized agent
    if classification.handoff_agent == "developer_agent":
        final_result = await Runner.run(developer_agent, input_text)
    elif classification.handoff_agent == "sre_agent":
        final_result = await Runner.run(sre_agent, input_text)
    # ... etc

2. Context Preservation

# Include conversation history for better classification
if query_context.history:
    history_text = "\n".join([
        f"{msg.get('role', 'unknown')}: {msg.get('content', '')}"
        for msg in query_context.history[-5:]  # Last 5 messages
    ])
    input_text += f"\n\nConversation History:\n{history_text}"

3. Metadata-Rich Responses

return QueryResponse(
    response=final_result.get_markdown() if final_result else "No response",
    metadata={
        "category": result.category,
        "handoff_agent": result.handoff_agent,
        "confidence_score": result.confidence_score,
        "reasoning": result.reasoning,
    },
)

Benefits of the Coordinator Pattern

1. Specialized Expertise

Each agent can focus on mastering their domain rather than being mediocre across all domains.

2. Maintainable Architecture

• Easy to add new agent types
• Clear separation of concerns
• Independent agent development and testing

3. Configurable Routing Logic

• Non-technical team members can update routing rules
• A/B testing of routing strategies
• Easy to adapt to changing business needs

4. Observable and Debuggable

• Clear routing decisions with reasoning
• Confidence scores for quality monitoring
• Detailed metadata for analytics

5. Scalable Development

• Teams can specialize in different agents
• Parallel development of agent capabilities
• Independent deployment and updates

Challenges and Solutions

Challenge 1: Classification Accuracy

Problem: Misclassified queries get routed to the wrong expert.

Solutions:

• Comprehensive training examples in configuration
• Confidence thresholds with human review fallbacks
• Continuous monitoring and feedback loops
• Regular retraining based on misclassification patterns

Challenge 2: Agent Capability Overlap

Problem: Multiple agents might be able to handle certain queries.

Solutions:

• Clear domain boundaries in configuration
• Primary/secondary agent routing
• Agent consultation mechanisms
• Hybrid responses combining multiple agents

Challenge 3: Context Switching Overhead

Problem: Routing adds latency and complexity.

Solutions:

• Parallel agent pre-loading for common scenarios
• Caching of classification decisions for similar queries
• Streaming responses during agent processing
• Optimized model selection per use case

Advanced Implementation Techniques

1. Multi-Stage Routing

# First stage: Broad category (Technical vs Product vs Business)
# Second stage: Specific sub-category within domain
async def multi_stage_classify(self, query):
    broad_category = await self.broad_classifier.classify(query)

    if broad_category == "technical":
        specific_category = await self.technical_classifier.classify(query)
        return f"technical_{specific_category}"

    return broad_category

2. Agent Ensemble Approaches

async def ensemble_response(self, query, category):
    if category in ["ambiguous", "complex"]:
        # Get responses from multiple agents
        responses = await asyncio.gather(
            self.developer_agent.run(query),
            self.sre_agent.run(query),
            self.product_agent.run(query)
        )

        # Use a meta-agent to synthesize the best response
        return await self.synthesis_agent.combine(responses, query)

    return await self.single_agent_response(query, category)

3. Dynamic Agent Loading

class CoordinatorAgent:
    def __init__(self):
        self.agent_registry = {}
        self.load_agents_from_config()

    def load_agents_from_config(self):
        """Dynamically load agents based on configuration"""
        for agent_config in self.config.agents:
            agent_class = import_class(agent_config.class_path)
            self.agent_registry[agent_config.name] = agent_class(agent_config.params)

    async def route_to_agent(self, agent_name: str, query: str):
        if agent_name not in self.agent_registry:
            raise ValueError(f"Unknown agent: {agent_name}")

        return await self.agent_registry[agent_name].run(query)

Conclusion

Multi-agent coordinators represent a powerful architectural pattern for building sophisticated AI systems. By embracing specialization over generalization, we can create systems that are:

• More effective at solving complex problems
• More maintainable with clear separation of concerns
• More scalable for teams and development processes
• More adaptable to changing requirements

The key insight is that intelligence isn’t just about individual agent capabilities—it’s about orchestrating specialized agents effectively. A well-designed coordinator can make the sum greater than its parts.

As AI systems become more complex and handle more diverse use cases, the coordinator pattern will become increasingly essential. Start simple, measure everything, and let your system evolve based on real usage patterns.

The future of AI isn’t a single superintelligent agent—it’s intelligent orchestration of specialized AI experts working together seamlessly.
