If you’ve just set up a ClickHouse cluster, the next scary step is: “Okay… now how do I actually create tables the right way so I don’t regret everything in six months?”

This post walks through that step in detail.

We’ll focus on how to design and create tables in a distributed ClickHouse deployment: local vs Distributed tables, shards, replicas, ON CLUSTER, sharding keys, replication, and the operational gotchas people usually only discover in production.

You don’t need to be a ClickHouse guru—just comfortable with SQL and basic distributed-systems ideas.

1. Mental model: what “distributed ClickHouse” actually means

Before we touch CREATE TABLE, you need a clear mental picture of the main pieces:

  • Shard – a subset of the data. Different shards hold different rows.
  • Replica – a copy of the data for a given shard. Replicas hold the same rows, for high availability and read scalability.
  • Local tables – physical storage tables on each node (usually MergeTree or ReplicatedMergeTree).
  • Distributed tables – logical “router” tables that sit on top of local tables and fan queries/inserts out to shards. They don’t store data themselves. (ClickHouse)
  • Keeper (ZooKeeper or ClickHouse Keeper) – coordination service used for replication and distributed DDL (e.g., ON CLUSTER). (ClickHouse)

A very common pattern per shard:

[ events_local ]  <-- ReplicatedMergeTree
       ^
       | (replication within shard)
       v
[ events_local ]  <-- ReplicatedMergeTree

then a cluster‑wide logical view:

[ events_dist ]   <-- Distributed over all events_local tables

So “creating a table in a distributed ClickHouse deployment” usually means:

  1. Define local tables (one per shard, per replica).
  2. Define Distributed tables that point to those local tables.
  3. Do it in a way that survives schema changes, node failures, and future growth.

2. Cluster config & macros: the plumbing your DDL depends on

Table creation in a cluster relies on two key configuration blocks:

  1. <remote_servers> – describes your cluster topology (shards & replicas). (ClickHouse)
  2. <macros> – defines variables like {shard} and {replica} that you use in table definitions. (ClickHouse)

A minimal cluster config might look like this (e.g. /etc/clickhouse-server/config.d/cluster.xml):

<clickhouse>
  <remote_servers>
    <main_cluster>
      <shard>
        <replica>
          <host>ch1</host>
          <port>9000</port>
        </replica>
        <replica>
          <host>ch2</host>
          <port>9000</port>
        </replica>
      </shard>
      <shard>
        <replica>
          <host>ch3</host>
          <port>9000</port>
        </replica>
        <replica>
          <host>ch4</host>
          <port>9000</port>
        </replica>
      </shard>
    </main_cluster>
  </remote_servers>

  <macros>
    <shard>01</shard>    <!-- set differently on each node -->
    <replica>ch1</replica>
  </macros>

  <keeper_server>…</keeper_server> <!-- ZooKeeper or ClickHouse Keeper -->
</clickhouse>

Each node has the same <remote_servers>, but different <macros> (at least {shard} and {replica}).

Those macros become building blocks for replicated tables:

ENGINE = ReplicatedMergeTree(
    '/clickhouse/tables/{shard}/events_local',
    '{replica}'
)

ClickHouse substitutes {shard} and {replica} from your config, ensuring:

  • Each shard has its own replication path in Keeper.
  • Each replica knows which zk path to use. (ClickHouse)

You don’t need macros for a trivial setup, but they’re standard practice and save you pain later.

3. Table engines in a distributed cluster: who does what?

In a distributed deployment you’ll almost always combine:

  • MergeTree / ReplicatedMergeTree – for actual storage.
  • Distributed – for cluster-wide reads/writes. (ClickHouse)

Quick roles:

MergeTree

  • Non‑replicated.
  • Used for local tables when you don’t need replication (e.g., dev, PoC, or read-only derived tables).

ReplicatedMergeTree

  • Same as MergeTree but adds asynchronous replication via Keeper. (ClickHouse)
  • Each replica shares a ZooKeeper/ClickHouse Keeper path; merges & mutations are coordinated.

Typical engine snippet:

ENGINE = ReplicatedMergeTree(
    '/clickhouse/tables/{shard}/events_local',  -- Keeper path
    '{replica}'                                  -- replica ID (macro)
)
PARTITION BY toYYYYMM(event_time)
ORDER BY (user_id, event_time)

Distributed

  • Holds no data.

  • Knows:

    • cluster name
    • database name
    • local table name
    • optional sharding key expression for routing inserts. (devdoc.net)

Example:

ENGINE = Distributed(
    'main_cluster',      -- cluster
    'analytics',         -- remote DB
    'events_local',      -- remote table
    cityHash64(user_id)  -- sharding key expression
)

4. Designing the schema: partitions, ORDER BY, and what matters for distribution

ClickHouse is weird (in a good way) if you’re coming from traditional RDBMSes. When you’re designing tables for a distributed cluster, watch three things:

  1. Primary key / ORDER BY
  2. Partition key
  3. Sharding key (for the Distributed table)

4.1 ORDER BY (a.k.a. the primary index)

In MergeTree-family tables, ORDER BY defines the sort key, which is used to build sparse indexes and perform efficient range scans. (ClickHouse)

Good choices:

  • Time-series events: ORDER BY (user_id, event_time) or ORDER BY (event_time, user_id)
  • Metrics: ORDER BY (metric_date, metric_name, dimension_id)

You want a key that:

  • Matches your most common WHERE / GROUP BY patterns.
  • Has reasonable cardinality (too low = large ranges to scan).

4.2 Partitions

Partitions group data into logical chunks (e.g., by month). They matter for:

  • TTL deletions
  • Efficient ALTER TABLE … DROP PARTITION
  • Faster queries when you filter on the partition key (ClickHouse)

Example for a daily partition:

PARTITION BY toDate(event_time)

In a distributed cluster, you want the same partitioning on every shard. That way, dropping a partition or moving data behaves consistently everywhere.

4.3 Sharding key (for Distributed engine)

This is separate from partition key and ORDER BY. The Distributed table uses it to decide which shard gets each inserted row. (ClickHouse)

Typical options:

  • User-centric workloads: cityHash64(user_id)
  • Tenant-based: cityHash64(tenant_id)
  • Random-ish: rand() or cityHash64(id) when access is mostly full-table scans

Guidelines:

  • Pick a key that evenly spreads data across shards.
  • If possible, align it with query access patterns. For example, if most queries filter by tenant_id, using tenant_id as sharding key means most queries only hit a single shard.

5. Step-by-step: creating local tables in a distributed cluster

Let’s say you want to store an events fact table in database analytics.

5.1 Create the database on all nodes

In a simple setup:

CREATE DATABASE IF NOT EXISTS analytics ON CLUSTER main_cluster;

ON CLUSTER sends this DDL to all the hosts in main_cluster via the distributed DDL mechanism (Keeper), so each node gets the same database. (ClickHouse)

5.2 Create the local replicated table

Now create a local table that will physically store data on each shard/replica:

CREATE TABLE IF NOT EXISTS analytics.events_local
ON CLUSTER main_cluster
(
    event_time   DateTime,
    user_id      UInt64,
    event_type   LowCardinality(String),
    properties   String
)
ENGINE = ReplicatedMergeTree(
    '/clickhouse/tables/{shard}/events_local',  -- Keeper path (with macros)
    '{replica}'                                 -- replica ID macro
)
PARTITION BY toYYYYMM(event_time)
ORDER BY (user_id, event_time)
SETTINGS index_granularity = 8192;

Key points:

  • ON CLUSTER main_cluster makes sure the same table is created on every node in the cluster definition.
  • The ReplicatedMergeTree engine path uses macros so each shard/replica gets the correct Keeper path. (ClickHouse)
  • You can tune partitioning & ORDER BY for your workload.

At this point:

  • Each shard owns unique rows.
  • Each shard has multiple replicas of events_local, kept in sync by replication.

6. Building the Distributed table on top

Now create a cluster-wide logical view that lets you query all shards as if it were a single table:

CREATE TABLE IF NOT EXISTS analytics.events_dist
ON CLUSTER main_cluster
AS analytics.events_local
ENGINE = Distributed(
    'main_cluster',       -- cluster name from <remote_servers>
    'analytics',          -- remote database
    'events_local',       -- remote table
    cityHash64(user_id)   -- sharding key
);

What this does:

  • AS analytics.events_local copies the column structure.
  • Distributed('main_cluster', 'analytics', 'events_local', …) ties it to all events_local tables in that cluster. (ClickHouse)
  • cityHash64(user_id) is your sharding function—each node uses it to route inserts.

Now:

  • Reads from events_dist fan out to all shards in parallel.
  • Inserts into events_dist are routed to a single shard based on the sharding key.

7. How inserts really work: internal_replication, quorum, and friends

When you insert into a Distributed table over replicated local tables, there are a few important settings. The full matrix can get hairy, but here’s the intuition.

7.1 internal_replication

This setting lives on the Distributed table.

  • internal_replication = 1 (typical)

    • The Distributed table sends data to one replica per shard.
    • That replica writes into ReplicatedMergeTree.
    • Replication then propagates to other replicas.

  • internal_replication = 0

    • The Distributed table sends data to every replica in a shard.
    • This is uncommon with ReplicatedMergeTree, because you’re doubling network/write load and fighting the replication mechanism.

With ReplicatedMergeTree, you almost always want internal_replication = 1. (Stack Overflow)

Example:

ALTER TABLE analytics.events_dist
MODIFY SETTING internal_replication = 1;

7.2 insert_distributed_sync & insert_quorum (quick overview)

  • insert_distributed_sync = 1

    • Wait until data is written to remote nodes (via Distributed) before returning.

  • insert_quorum (for ReplicatedMergeTree)

    • Ensures a write is replicated to at least N replicas before a commit is considered successful.

The exact interactions are nuanced (and can evolve), but the mental model:

  • Distributed settings control how your query node talks to shard nodes.
  • ReplicatedMergeTree settings control how replicas within a shard coordinate.

For many setups, you start with:

SET insert_distributed_sync = 1;
SET insert_quorum = 2;  -- if you have at least 2 replicas per shard

and measure the impact before tuning further. (Stack Overflow)

8. ON CLUSTER and distributed DDL: keeping schemas in sync

Without extra help, CREATE TABLE only affects the node you send it to.

In a cluster, that’s a recipe for:

  • Slightly different schemas on different nodes.
  • Queries failing only on specific replicas.
  • 3 a.m. debugging sessions.

The ON CLUSTER clause fixes that:

CREATE TABLE ... ON CLUSTER main_cluster ...;
ALTER TABLE ... ON CLUSTER main_cluster ...;
DROP TABLE ... ON CLUSTER main_cluster ...;

How it works (simplified):

  1. Your node writes the DDL into a distributed DDL log in Keeper.
  2. Every node with that cluster name picks up the entry and executes it locally.
  3. You can monitor progress in system.distributed_ddl_queue. (ClickHouse)

Important caveats:

  • All nodes must have the same <remote_servers> cluster definition.
  • If a node is down, the DDL waits in a queue and is applied when the node comes back (unless you clear it).
  • If you bypass ON CLUSTER for schema changes, you can create subtle inconsistencies between replicas.

If you find yourself repeating DDL “just in case” on different nodes, that’s a smell: you should be using ON CLUSTER.

9. Patterns for tables in a distributed ClickHouse deployment

Let’s look at a few common patterns and how table creation fits each.

9.1 Sharded fact table + Distributed “front”

We already saw this pattern with events:

  • analytics.events_local ReplicatedMergeTree, sharded and replicated.
  • analytics.events_dist Distributed engine, for querying and inserting.

You normally:

  • Write to events_dist from applications.
  • Query events_dist for ad-hoc analysis.
  • Possibly query events_local directly for maintenance or troubleshooting.

9.2 Dimension tables: small and often replicated

Dimension tables (e.g., users, accounts) are often small enough to:

  • Store fully on each shard (no sharding), and
  • Still replicate for HA.

You can:

  1. Create a replicated local dimension table:

     CREATE TABLE IF NOT EXISTS analytics.users_local
 ON CLUSTER main_cluster
 (
     user_id   UInt64,
     name      String,
     country   FixedString(2)
 )
 ENGINE = ReplicatedMergeTree(
     '/clickhouse/tables/{shard}/users_local',
     '{replica}'
 )
 PARTITION BY tuple()
 ORDER BY user_id;

  2. Either:

    • Query users_local via a Distributed table, or
    • Use table functions like clusterAllReplicas() when needed. (ClickHouse)

For many workloads, dimension tables are small enough that the exact sharding scheme is less critical, as long as every shard has complete data.

9.3 Aggregations via local materialized views

Common pattern:

  • Write raw data into events_dist.
  • On each node, a local materialized view consumes events_local and writes to a per-shard aggregate table.
  • A Distributed aggregate table provides cluster-wide view.

Example:

CREATE TABLE analytics.events_agg_local
ON CLUSTER main_cluster
(
    day       Date,
    event_type LowCardinality(String),
    cnt       UInt64
)
ENGINE = ReplicatedMergeTree(
    '/clickhouse/tables/{shard}/events_agg_local',
    '{replica}'
)
PARTITION BY day
ORDER BY (day, event_type);

CREATE MATERIALIZED VIEW analytics.events_to_agg
ON CLUSTER main_cluster
TO analytics.events_agg_local
AS
SELECT
    toDate(event_time) AS day,
    event_type,
    count() AS cnt
FROM analytics.events_local
GROUP BY day, event_type;

CREATE TABLE analytics.events_agg_dist
ON CLUSTER main_cluster
AS analytics.events_agg_local
ENGINE = Distributed(
    'main_cluster',
    'analytics',
    'events_agg_local',
    cityHash64(event_type)
);

This pattern lets you:

  • Distribute aggregation work across shards.
  • Query aggregated data efficiently via events_agg_dist.

10. Operational stuff you’ll wish you knew sooner

10.1 Schema changes (ALTER TABLE)

When you alter a table in a distributed setup:

  • Always use ON CLUSTER, unless you intentionally want divergence.

Example:

ALTER TABLE analytics.events_local
ON CLUSTER main_cluster
ADD COLUMN device String AFTER event_type;

If you forget ON CLUSTER:

  • That column might only exist on some nodes.
  • Distributed queries will fail when they hit a replica without the column.

You can also alter the Distributed table, but typically the columns and types come from the underlying local table schema.

10.2 Adding a new replica

When you add replicas, you usually:

  1. Add the node to <remote_servers>’ cluster layout.
  2. Configure correct <macros> for {shard} and {replica}.
  3. Start ClickHouse; create the same ReplicatedMergeTree tables using the same Keeper path.
  4. The new replica pulls data from existing replicas and catches up. (Altinity® Knowledge Base for ClickHouse®)

As long as:

  • The replication path (e.g. /clickhouse/tables/01/events_local) is the same, and
  • The schema matches,

the new replica will “join the party” and backfill data.

10.3 Monitoring distributed DDL

Watch:

  • system.distributed_ddl_queue – status of cluster-wide DDL. (ClickHouse)
  • system.replicas – replication delays & errors.
  • system.parts – number/sizes of parts for each table.

These system tables help you spot:

  • Nodes that didn’t apply a DDL.
  • Replicas that are lagging behind.
  • Shards that are accumulating too many parts (bad insert patterns).

11. A practical checklist: creating a new table in a distributed ClickHouse cluster

When you’re about to introduce a new table, run through this checklist:

  1. Cluster topology confirmed

    • <remote_servers> defines your cluster correctly.
    • <macros> set per node ({shard}, {replica}).
    • Keeper (ZooKeeper or ClickHouse Keeper) is healthy.

  2. Schema design

    • Columns and types defined.
    • ORDER BY matches query patterns.
    • PARTITION BY suits your data lifecycle (e.g., daily/monthly partitions).
    • Compression, TTL, and indexes considered if needed.

  3. Local table definition

    • Use ReplicatedMergeTree for anything important.
    • Path uses macros: '/clickhouse/tables/{shard}/table_name'.
    • CREATE TABLE ... ON CLUSTER your_cluster.

  4. Distributed table definition

    • Distributed('cluster', 'db', 'local_table', sharding_key_expr).
    • Sharding key spreads data well and aligns with query filters.
    • internal_replication = 1 if using ReplicatedMergeTree.

  5. Application wiring

    • Writes go to the Distributed table, not directly to _local tables (unless you know why).
    • Reads usually go to the Distributed table as well.

  6. Schema changes

    • Always ALTER TABLE ... ON CLUSTER.
    • Verify on system.columns across nodes if you suspect inconsistency.

  7. Monitoring

    • Watch replication (system.replicas).
    • Watch distributed DDL queue (system.distributed_ddl_queue).
    • Track performance and part counts (system.parts).

Print this list, stick it near your terminal, and you’ll avoid a bunch of subtle cluster headaches.

12. Summary and further reading

We covered quite a lot:

  • The building blocks of a distributed ClickHouse cluster: shards, replicas, local and Distributed tables, Keeper.
  • How MergeTree / ReplicatedMergeTree work with the Distributed engine to store and query data across the cluster. (ClickHouse)
  • How to design partitions, ORDER BY and sharding keys for distributed workloads. (ClickHouse)
  • Using ON CLUSTER and macros to keep table definitions consistent. (ClickHouse)
  • Practical patterns: sharded fact tables, replicated dimensions, materialized-views-based aggregations.
  • Operational concerns around schema changes, adding replicas, and monitoring.

If you want to go deeper, these are excellent next reads:

  • ClickHouse Docs – Table Engines (MergeTree family + Distributed) (ClickHouse)
  • Replication & Sharding examples in the official deployment guides (ClickHouse)
  • Distributed DDL (ON CLUSTER) documentation (ClickHouse)
  • Altinity & PostHog engineering blogs on ClickHouse sharding and replication (PostHog)

If you’d like, next we can walk through a concrete topology (e.g., 2 shards × 2 replicas) and write everything end-to-end: config, DDL, and some example queries and failure scenarios.

You may also enjoy
