Type-Safe Backend Evolution: Using tRPC, Zod, and OpenAPI 4 to Prevent Silent API Breaks

You’re on call. It’s 2:13 AM.

A partner team pings you: “Your user API just started returning 500s when we deploy. We didn’t change anything.”

You did, though. Yesterday you refactored a handler, renamed a field, tweaked a type. TypeScript built fine. Unit tests passed. Your frontend monorepo is happy.

But someone else’s Go client, generated months ago from an old OpenAPI spec, is not happy at all.

That’s a silent API break: the backend evolved, the contract didn’t, and nothing screamed until production traffic did.

This post is about building a stack where:

TypeScript catches mistakes across the client/server boundary.
Your API contract is generated from the same source of truth as your runtime validation.
Every change to that contract is diffed and checked for breakage in CI, ideally in a way that plays nicely with the upcoming OpenAPI 4 “Moonwalk” effort. (OpenAPI Initiative)

We’ll get there with three tools:

tRPC – end-to-end TypeScript RPC framework. (trpc.io)
Zod – TypeScript-first runtime schema validation & type inference. (Zod)
OpenAPI 3.x now, 4 later – the ubiquitous API contract format, currently at 3.2.0, with v4 “Moonwalk” under active design. (OpenAPI Initiative Publications)

1. The Real Enemy: Silent API Breaks

APIs want to drift.

You start with:

GET /users/{id}
{
  "id": "123",
  "name": "Ada Lovelace",
  "age": 29
}

A month later someone “just”:

Renames name → fullName
Makes age optional
Adds email as required

TypeScript keeps compiling, because your backend code still type-checks. Your own frontend, which imports shared types from the backend, gets compile errors and you fix them. But:

A Python client that deserializes name breaks at runtime.
A mobile app compiled with an old model silently drops email.
A partner’s codegen client still thinks age is required.

The core problem:

Your runtime contract (what the API actually returns) and your static types (what your code thinks exists) drift apart over time.

And if you don’t have automated contract diffing, you only learn that after an outage.

We want a pipeline that makes it hard to accidentally change the contract without knowing:

Types break → TypeScript yells.
Payload shape breaks → Zod yells.
Contract changes → OpenAPI diff tools yell.

Let’s build that.

2. tRPC + Zod: End-to-End Type Safety Inside Your World

First, we fix type safety for your own TypeScript clients.

2.1 What tRPC brings to the table

tRPC is basically:

“Call backend functions directly from the frontend, but with real HTTP under the hood and no codegen – just TypeScript inference.” (trpc.io)

You define a router on the server:

// src/trpc/router.ts
import { initTRPC } from "@trpc/server";
import { z } from "zod";

const t = initTRPC.create();

export const appRouter = t.router({
    getUser: t.procedure
        .input(
            z.object({
                id: z.string().uuid(),
            })
        )
        .output(
            z.object({
                id: z.string().uuid(),
                name: z.string(),
                age: z.number().int().nonnegative(),
            })
        )
        .query(async ({ input }) => {
            const user = await db.user.findById(input.id);
            // Zod will enforce this at runtime
            return user;
        }),
});

// Export type for client
export type AppRouter = typeof appRouter;

On the client:

// src/trpc/client.ts
import { createTRPCClient, httpBatchLink } from "@trpc/client";
import type { AppRouter } from "../trpc/router";

export const trpc = createTRPCClient<AppRouter>({
    links: [
        httpBatchLink({
            url: "https://api.example.com/trpc",
        }),
    ],
});

// Usage
const user = await trpc.getUser.query({ id: "uuid-string" });
// user has type: { id: string; name: string; age: number }

If you change the server’s output() schema, the client’s inferred type changes automatically. Any mismatched usage (user.age.toFixed() when you made age optional) fails at compile time.

2.2 Zod closes the runtime gap

Zod is a TypeScript-first validation library:

You define schemas (z.object({ ... })).
It validates data at runtime.
It also infers the TypeScript type from the schema. (Zod)

In tRPC, those .input() and .output() Zod schemas are used both for:

Runtime validation of HTTP payloads.
Static typing of client/server code.

So if your database returns age: "29" as a string by mistake, .output() validation fails before that bad shape leaks over the wire.

Inside a TypeScript monorepo, tRPC + Zod virtually eliminate silent breaks.

But that only helps if all your consumers are TypeScript and speak tRPC.

The real world… is not that kind.

3. Beyond the Monorepo: Why We Still Need OpenAPI

Once you have:

Mobile apps
Backend-to-backend integrations
External partners
Polyglot microservices

you need a language-neutral description of your API.

That’s what the OpenAPI Specification (OAS) gives you: a standard way to describe HTTP APIs – endpoints, parameters, schemas – so tools and humans can understand them without reading source code. (OpenAPI Initiative Publications)

OpenAPI specs power:

Documentation (Swagger UI, Redoc, etc.)
Code generation (clients in Go, Java, Swift…)
Contract testing & breaking change detection
Governance & API catalogs

Currently, the spec is at 3.2.0 with widespread tooling support. (OpenAPI Initiative Publications)

3.1 What about OpenAPI 4 “Moonwalk”?

OpenAPI 4 (code name Moonwalk) is the next major revision under active work by a dedicated SIG. The goals include: (OpenAPI Initiative)

Better semantics – making the meaning of operations clearer for humans and LLMs.
More explicit signatures – ways to identify API operations from HTTP details.
Cleaner modularity & foundational interfaces – easier for tooling authors.
A focus on mechanical upgrade from 3.x → 4.0.

Crucially, the OpenAPI Initiative has emphasized that Moonwalk is an ongoing project and the timeline for a 4.0.0 release is still open-ended as of late 2025. (OpenAPI Initiative)

So today, we’ll generate OpenAPI 3.x from tRPC/Zod, but design with 4 in mind (good semantics, stable operation signatures, etc.).

4. One Source of Truth: Zod Schemas → tRPC → OpenAPI

The dream is:

“I define my models once, and they become: – runtime validation – TypeScript types – OpenAPI schemas – eventually OpenAPI 4-compatible contracts”

Zod is the obvious candidate for that “once”.

4.1 Designing Zod schemas as your domain model

Let’s start by extracting reusable Zod schemas:

// src/schemas/user.ts
import { z } from "zod";

export const UserId = z.string().uuid();

export const User = z.object({
    id: UserId,
    name: z.string().min(1),
    age: z.number().int().nonnegative(),
    email: z.string().email().optional(),
});

export type User = z.infer<typeof User>;

This one module now backs:

Validation in your handlers.
TypeScript types.
(Soon) OpenAPI schemas.

4.2 Wiring these schemas into tRPC

// src/trpc/router.ts
import { initTRPC } from "@trpc/server";
import { z } from "zod";
import { UserId, User } from "../schemas/user";

const t = initTRPC.create();

export const appRouter = t.router({
    getUser: t.procedure
        .meta({
            // will be useful when generating OpenAPI
            openapi: {
                summary: "Get a user by ID",
                path: "/users/{id}",
                method: "GET",
                tags: ["Users"],
            },
        })
        .input(z.object({ id: UserId }))
        .output(User)
        .query(async ({ input }) => {
            const user = await db.user.findById(input.id);
            if (!user) {
                throw new Error("User not found");
            }
            return user;
        }),
});

We’ve already got:

End-to-end TS types for our own clients.
Runtime validation for inputs and outputs.

Next step is to let these same Zod schemas feed OpenAPI.

5. Generating OpenAPI from Zod

There are several libraries that take Zod schemas and generate OpenAPI:

zod-openapi (npm)
@anatine/zod-openapi (npm)
@asteasolutions/zod-to-openapi (GitHub)

They all follow the same idea:

“Decorate Zod schemas and routes with a bit of metadata → generate a full OpenAPI document.”

Here’s an example using zod-openapi-style APIs (simplified):

// src/openapi.ts
import {
    OpenAPIRegistry,
    OpenApiGeneratorV3,
} from "@asteasolutions/zod-to-openapi";
import { z } from "zod";
import { User, UserId } from "./schemas/user";

const registry = new OpenAPIRegistry();

// Describe your schemas
registry.register("User", User);
registry.register("UserId", UserId);

// Describe your route
registry.registerPath({
    method: "get",
    path: "/users/{id}",
    tags: ["Users"],
    description: "Get a user by ID",
    request: {
        params: z.object({
            id: UserId,
        }),
    },
    responses: {
        200: {
            description: "User found",
            content: {
                "application/json": {
                    schema: User,
                },
            },
        },
        404: {
            description: "User not found",
        },
    },
});

// Generate spec
const generator = new OpenApiGeneratorV3(registry.definitions);

export const openApiDoc = generator.generateDocument({
    openapi: "3.1.0",
    info: {
        title: "My Service",
        version: "1.0.0",
    },
    servers: [{ url: "https://api.example.com" }],
});

You can then serialize openApiDoc to YAML/JSON at build time and ship it with your service or publish it centrally.

Note: Today these generators target OpenAPI 3.x. Because 4 is meant to be mechanically upgradable from 3.x, investing in well-structured 3.x docs is still future-proof. (OpenAPI Initiative)

6. Generating OpenAPI from tRPC Routers

Hand-registering every path is boring. tRPC already knows:

The input and output types (via Zod).
The URL shape (via your router setup / meta).
The HTTP method you want to expose.

The ecosystem has created several bridges to generate OpenAPI from tRPC:

trpc-openapi (original, now archived but widely used and forked) (GitHub)
@dokploy/trpc-openapi (maintained fork) (GitHub)
trpc-to-openapi (npm)
openapi-trpc / similar tools (GitHub)

These typically work like:

Extend initTRPC with OpenAPI metadata type.
Annotate tRPC procedures with meta.openapi.
Run a generator that walks your router and emits a spec.

Sketch with trpc-to-openapi-style configuration:

// src/trpc/openapi.ts
import { initTRPC } from "@trpc/server";
import { OpenApiMeta } from "trpc-to-openapi"; // or @dokploy/trpc-openapi
import { z } from "zod";
import { User, UserId } from "../schemas/user";

const t = initTRPC.meta<OpenApiMeta>().create();

const publicProcedure = t.procedure;

export const appRouter = t.router({
    getUser: publicProcedure
        .meta({
            openapi: {
                method: "GET",
                path: "/users/{id}",
                summary: "Get a user by ID",
                tags: ["Users"],
            },
        })
        .input(
            z.object({
                id: UserId,
            })
        )
        .output(User)
        .query(async ({ input }) => {
            return db.user.findByIdOrThrow(input.id);
        }),
});

// Later, in some build script:
import { generateOpenApiDocument } from "trpc-to-openapi";

const openApiDoc = generateOpenApiDocument(appRouter, {
    title: "My Service",
    version: "1.2.3",
    baseUrl: "https://api.example.com",
});

Now your tRPC router is the single source of truth, and the OpenAPI spec is derived from it.

This plays extremely well with Moonwalk’s goals of semantics, signatures, and mechanical upgrading: you already attach explicit summaries, tags, and paths that can later map into richer 4.0 structures. (OpenAPI Initiative)

7. Preventing Silent Breaks with OpenAPI Diff in CI

So far, we have:

tRPC + Zod: type-safe implementation and type-safe TypeScript clients.
OpenAPI 3.x generated from the same source of truth.

Now we need to stop a developer from casually committing a breaking change and merging it.

7.1 Breaking-change detectors for OpenAPI

There’s a small ecosystem of tools that compare two OpenAPI specs and classify changes as breaking or non-breaking:

oasdiff – diff, changelog, and breaking change detection; has a GitHub Action. (OASDiff)
openapi-changes – pb33f’s “world’s sexiest OpenAPI breaking change detector,” used as a general diff & changelog engine. (pb33f.io)
openapi-diff – libraries and CLIs from Azure and OpenAPITools used to detect breaking changes in large-scale API ecosystems. (GitHub)

Under the hood, these tools:

Parse both specs into an internal model.
Compare operations, parameters, schemas.
Tag changes as added / removed / modified and breaking / non-breaking. (pb33f.io)

For example:

Breaking: removing a path, changing a response type, making a required field missing or more restrictive.
Non-breaking: adding a new optional field, adding an endpoint, relaxing a constraint.

7.2 Example: CI check with oasdiff

Let’s say your build produces openapi.yaml. You keep the last released spec in openapi-baseline.yaml.

A GitHub Actions workflow might look like:

name: API Contract Check

on:
    pull_request:
        paths:
            - "src/**"
            - "openapi/**"

jobs:
    openapi-diff:
        runs-on: ubuntu-latest

        steps:
            - uses: actions/checkout@v4

            - name: Install deps
              run: npm ci

            - name: Build OpenAPI spec
              run: npm run generate:openapi # writes to openapi/current.yaml

            - name: Check for breaking changes
              uses: oasdiff/oasdiff-action@main
              with:
                  base: openapi/baseline.yaml
                  revision: openapi/current.yaml
                  # Only fail on breaking changes
                  additional-args: "--format text --breaking-only"

If someone changes User.age from number to string, or removes a field marked as required in the previous spec, the action fails and surfaces a human-readable report.

No more “oops we broke the mobile app in prod but TypeScript was fine.”

8. A Concrete Refactor Walkthrough

Let’s put the whole pipeline together with a small evolution story.

8.1 v1: Simple user model

Your Zod schema:

export const User = z.object({
    id: UserId,
    name: z.string(),
    age: z.number().int().nonnegative(),
});

Your tRPC procedure outputs User. You generate openapi-v1.yaml from tRPC.

8.2 Refactor: add emails, make age optional

Product decides:

age should be optional (users can skip it).
email should be required.

You change the schema:

export const User = z.object({
    id: UserId,
    name: z.string(),
    age: z.number().int().nonnegative().optional(), // changed
    email: z.string().email(), // new, required
});

What happens?

tRPC + TypeScript

Anywhere in your TS code that assumed user.age: number now sees user.age: number | undefined and fails to compile until you handle the optional case.
Zod runtime validation

If some legacy record in the DB is missing email, Zod will throw on output, and you’ll discover that before it silently leaks incorrect shapes to consumers.
OpenAPI diff

You regenerate openapi-v2.yaml.
- oasdiff / openapi-changes compares v1 vs v2.
- It sees that:
  - age became optional → typically non-breaking for clients (they can ignore it).
  - email is a new required response property → potentially breaking, because existing clients might not expect or handle it depending on your rules.
Your CI policy might say:
- “Required response fields added = breaking → major version bump or feature flag.”
So the PR fails until you either:
- Make email optional initially, or
- Introduce a v2 endpoint or new versioned schema.

The result: you can’t accidentally slide a contract-breaking change into main. You must either:

Explicitly version it.
Explicitly loosen it.
Or explicitly accept the breaking change and update the baseline spec.

9. Preparing for OpenAPI 4 (Without Waiting for It)

Moonwalk’s design principles – semantics, signatures, mechanical upgrade – reward teams that already treat their OpenAPI docs as structured, semantically rich contracts. (OpenAPI Initiative)

The tRPC + Zod + OpenAPI stack helps you get there:

Semantics You already attach meaningful summary, description, tags, and well-named schemas when generating from Zod/tRPC. That metadata is useful today and will be even more useful for LLM-driven tooling tomorrow.
Signatures Explicit path + method + operationId in generated specs give each operation a stable identity, which aligns with Moonwalk’s focus on signatures as a first-class concept.
Mechanical upgrade Because your OpenAPI documents are machine-generated with consistent patterns, automated 3.x → 4.x migration tools (one of Moonwalk’s goals) have an easier job. (OpenAPI Initiative)

Meanwhile, diff tools like openapi-changes and oasdiff already support multiple OpenAPI versions and Swagger 2.0, and are likely to support 4.x as it stabilizes. (GitHub)

You don’t need to wait for the 4.0.0 badge to start evolving safely.

10. A Practical Adoption Checklist

If you want to move towards type-safe backend evolution with this stack, here’s a pragmatic path:

Introduce Zod for validation
- Start with one endpoint.
- Replace ad-hoc checks with Zod schemas.
- Export z.infer<typeof Schema> to use in your TypeScript types.
Adopt tRPC where it makes sense
- Ideal for monorepo full-stack apps (Next.js, Remix, etc.). (trpc.io)
- Define routers using your existing Zod schemas.
- Swap your frontend’s manual fetch calls for trpcClient.procedure.query(...).
Generate an OpenAPI 3.x spec
- Choose a Zod → OpenAPI library (zod-openapi, @anatine/zod-openapi, zod-to-openapi) or tRPC → OpenAPI bridge (trpc-to-openapi, @dokploy/trpc-openapi). (GitHub)
- Wire it into your build: npm run generate:openapi.
- Publish the spec where other teams & tools can see it.
Add OpenAPI diff to CI
- Pick a diff tool (e.g., oasdiff or openapi-changes). (OASDiff)
- Keep a baseline spec (last release).
- Fail the pipeline on breaking changes.
Gradually tighten rules
- Start by just reporting changes.
- Later, fail on high-risk breaking changes (field removals, required → optional flips, etc.).
- Finally, enforce a policy: “No breaking change without explicit versioning plan.”
Add good semantics today
- Consistent tags, readable summaries, helpful descriptions.
- Stable operation IDs for all endpoints.
- These pay off now (docs & codegen) and later (LLM tooling, OpenAPI 4).

11. Key Takeaways & Further Reading

End-to-end type safety (tRPC + Zod) eliminates a whole class of bugs by letting TypeScript infer types across the network boundary and validate payloads at runtime. (trpc.io)
OpenAPI 3.x is still the lingua franca for cross-language API contracts, and the path to OpenAPI 4 “Moonwalk” runs right through well-structured 3.x docs. (OpenAPI Initiative Publications)
Generating OpenAPI directly from Zod/tRPC makes your code the canonical contract, not some stale YAML file.
Adding OpenAPI diff tools like oasdiff or openapi-changes to CI means no more silent contract drift – every breaking change becomes a deliberate choice. (OASDiff)

If you want to dig deeper:

tRPC docs (for v11) – how to structure routers, adapters, and clients. (trpc.io)
Zod docs – advanced schemas, transforms, and JSON Schema integration. (Zod)
zod-openapi, zod-to-openapi, and trpc-to-openapi READMEs – concrete generation examples. (GitHub)
OpenAPI “Moonwalk” SIG pages and blog posts – to understand where 4.0 is heading and why semantics & signatures matter. (OpenAPI Initiative)

If your team maintains even a single non-trivial API, investing in this pipeline is one of those rare moves that improves developer experience, reliability, and future-proofing at the same time.

And ideally, it keeps you from debugging contract drift at 2:13 AM.
